Track plan at a glance Name: Utah Colorado Western Scale: HO (1:87) Size: 28 x 33 feet Prototype: free-lance Period: 1967 Style: peninsula walkaround Minimum radii: 30″ on main line, 26″ on branch line Maximum grade: 1.5 percent Originally appeared in the May 1999 issue of Model Railroader. Click this link to download a PDF […]
Track plan at a glance Name: Walla Walla Valley Ry. Scale: HO (1:87) Size: 10 x 11 feet Prototype: Walla Walla Valley Ry. Period: 1968 Style: linear walkaround Mainline run: 24 feet Minimum radius: 15″ Minimum turnout: Peco medium radius Maximum grade: none Originally appeared in the 2005 issue of Great Model Railroads. Click here […]
Track plan at a glance Name: Waynesburg & Washington RR Scale: HO (1:87 standard gauge) Size: 17 x 18 feet Theme: Pennsylvania RR Period: summer 1957 Style: point to point with connection for continuous run Minimum radius: 18″ Minimum turnout: handlaid no. 6 with no. 4 in some yards Maximum grade: 2½ percent Originally appeared […]
Track plan at a glance Name: Western Route of the Boston & Maine Scale: HO (1:87) Size: 11 x 13 feet Theme: B&M with Maine Central interchange Period: late 1950s-early ’60s Style: center access with surrounding staging Mainline run: 67 feet (27 feet visible plus 40 feet in staging) Minimum radius: 31″ Minimum turnout: no. […]
Track plan at a glance Name: Wyoming Division of the Union Pacific Scale: HO (1:87) Size: 26 x 45½ feet Prototype: Union Pacific Era: 1938 to 1960 Style: around the walls with duckunder Minimum radii: main line 48″, branch line 36″ Minimum turnout: no. 8 Maximum grade: main line 1.8 percent, branch line 3.8 percent […]
Track plan at a glance Name: Waterbury Branch (New York, New Haven & Hartford RR Scale: HO (1:87) Size: 10 x 13 feet Prototype: New York, New Haven & Hartford RR Period: 1940-’50s Style: around the walls with operating pit Minimum radius: 23″ Minimum turnout: no. 5 Maximum grade: 3 percent Originally appeared in the […]
Track plan at a glance Name: Arvern Bay Terminal RR Scale: HO (1:87) Size: 12′-6″ x 18′-8″ Prototype: Eastern urban short line; fictitious subsidiary of the CNJ Period: September 1944 Style: around-the-walls Mainline run: 60 feet Minimum radius: 22″ on main line Minimum turnout: no. 4 Maximum grade: 4 percent Originally appeared in the March […]
Track plan at a glance Name: Bedroom layout Scale: HO (1:87) Minimum radius: 20″ Minimum turnout: no. 4 and no. 6 Originally appeared in the October 2001 issue of Model Railroader. Click on the link to download a PDF of this track plan […]
Track plan at a glance Name: Benedict & Wexford Scale: HO Size: 10 x 10 Minimum radius: 18″ Minimum turnout: no. 4 Maximum grade: 4 percent Originally appeared in the December 2000 issue of Model Railroader. Also appeared in 102 Realistic Track Plans. Click on the link to download a PDF of this track plan […]
Track plan at a glance Name: Bogg’s Landing & Trotwater RR Scale: HO (1:87) Size: 8 x 12 feet Theme: free-lance short line Period: 1930s Style: walk-in horseshoe Mainline run: 63 feet (72 feet with continuouss-run connection) Minimum radius: 18″ Minimum turnout: no. 4 Maximum grade: 4 percent Originally appeared in the June 2001 issue […]
Track plan at a glance Name: City Edge Scale: HO (1:87) Size: 24 x 40 feet Theme: fictional urban railroad based on locations in Chicago and St. Louis Era: 1950 to present day Style: around the walls Mainline run: 110 feet Minimum radius: 38″ on the main line and 22″ in the warehouse district Minimum […]
Track plan at a glance Name: Old Colony & South Shore RR Scale: HO (1:87.1) Size: 24′-6″ x 33′-6″ with an 8′-0″ x 16′-6″ staging area Prototype: Boston & Maine Period: 1920 to 1940 Style: walkaround Mainline run: 200 feet Minimum radius: 36″ Minimum turnout: no. 6 Maximum grade: 1 percent Originally appeared in the […]
