Name: Rock Island, Clay Center Branch Layout owner: Ken Jenkins Scale: HO (1:87:1) Size: 27 x 55 feet Prototype: Chicago, Rock Island & Pacific RR Locale: Northeast Kansas Era: fall 1969 Style: around the walls Mainline run: 150 feet Minimum radius: 25″ Minimum turnout: no. 6 (main), no. 5 (yards and spurs) Maximum grade: 1.25 […]
Name: Blue Ridge & Allegany Ry. Layout owner: Ron Hale Scale: HO (1:87.1) Layout size: 22′-6″ x 38′-6″ Prototype: freelanced, inspired by the Southern Ry. and Western Maryland Ry. Locale: Appalachian Mountains from Blue Ridge, N.C., to Allegany, Md. Era: 1952 Mainline run: 173 feet Minimum radius: 32″ (main), 28″ (branch) Minimum turnout: no. 6 […]
Name: Gulf, Colorado & Santa Fe Layout owner: David Kampsnider Scale: HO (1:87.1) Size: 26 x 30 feet Prototype: Atchison, Topeka & Santa Fe Ry. Locale: Oklahoma Era: 1951 Style: walk-in Mainline run: 100 feet Minimum radius: 34″ Minimum turnout: no. 6 (main), no. 5 (spurs) Maximum grade: 1 percent (main),2.2 percent (helix) Benchwork: 1 […]
[…]
Name: Chicago & North Western Ry. Layout owner: Don Drum Scale: HO (1:87.1) Size: 27 x 43 feet Prototype: C&NW Lakeshore Division, Ashland District (Eland, Wis., to Ashland, Wis.) Locale: northern Wisconsin Era: summer 1956 to 1960 Style: walk-in Benchwork: L-girder and open grid Height: 49″ to 55″ Roadbed: 1⁄2″ plywood, 1⁄2″ Homasote, and 1⁄4″ […]
Name: Geneva Subdivision Layout owner: Daryl Kruse Scale: N (1:160) Size: 25 x 48 feet Prototype: Union Pacific (ex-Chicago & North Western) Locale: Northern Illinois Era: Present Style: single deck Mainline run: 160 feet Minimum radius: 36″ Turnouts: no. 10 (mainline), no. 8 (secondary and yard track) Maximum grade: 0.5 percent Benchwork: open-grid Height: 55″ […]
[…]
Name: Rio Grande Summit Line Layout owner: John Mellowes Scale: HOn3 Size: 49′-6″ x 80′-21⁄2″ Prototype: freelanced, inspired by Denver & Rio Grande Western Locale: Southwestern Colorado Era: 1940 Style: walkaround Mainline run: 420 feet Minimum radius: 24″ Minimum turnout: no. 6 Maximum grade: 2 percent Benchwork: open grid Height: 42″ to 60″ Roadbed: cork […]
Name: The Hoosier Line Layout designer: Jack Simpson Scale: HO (1:87.1) Size: 24 x 40 feet Prototype: Monon RR Locale: Indiana Era: 1950s Style: walkaround Mainline run: 124 feet Minimum radius: 32″ Minimum turnout: no. 6 Maximum grade: 1⁄2 percent Benchwork: open grid Height: 43″ Roadbed: cork Track: Atlas code 83 Scenery: extruded-foam insulation board […]
Name: New Baltimore & Fair Haven Ry. Layout owner: Greg Rich Scale: HO (1:87.1) Size: 40 x 48 feet Locale: freelanced Era: 1928 Style: walk-in Minimum radius: 29″ Minimum turnout: no. 4 Maximum grade: 2.8 percent Benchwork: open grid Height: 441⁄2″ to 54″ Roadbed: Homasote on 1/2″ plywood Track: flextrack and handlaid code 83, 70, […]
Name: Georgia Great Southern Layout owner: Joe Gelmini Scale: N (1:160) Size: 18 x 60 feet Prototype: Southern Ry. Locale: Atlanta, Ga. to Mobile, Ala. Era: mid 1950s to 1970 Mainline run: 400 feet Minimum radius: 20″ Minimum turnout: no. 8 (main), no. 6 (yards and sidings) Maximum grade: 2 percent Benchwork: open grid, L […]
Check out this layout tour of Dean Ferris’ 25′ x 28′ N scale proto-lanced Northern Pacific-Great Northern mainline connecting the Pacific Northwest to Nevada/Calfifornia, just prior to the 1970 Burlington Northern merger. […]
