Consolidation 2836 steams across a country road at Junction, Ill., with the every-other-day freight between Flora and Shawneetown in September 1954. Philip R. Hastings photo […]
Western corner of the B&O
Classic logging Mallet
The 2-6-6-2T Mallet, exemplified by Weyerhauser No. 9, was perhaps the ultimate development of the logging locomotive. Compact, powerful, and flexible, the type was ideally suited to pulling heavy loads over rough, sharply curved track. Geared locomotives like the Shay also possessed these traits, but could not make the speed of a rod engine. Baldwin […]
Rock Island 4-8-4 at Joliet
Rock Island class R-67 Northern 5114 has just passed Joliet (Ill.) Union Station and crossed the GM&O/ATSF diamond as it steams toward Chicago with an eastbound freight in fall 1951. Wallace W. Abbey photo […]
Reading Pacific on the PRSL
Characteristic of the indignities suffered by steam in its final years, Reading G-3 Pacific 215, built in 1948 as a top-flight passenger engine, loafs along with a single coach on the Pennsylvania-Reading Seashore Lines in September 1955. Philip R. Hastings photo […]
Quiet Sunday on the DT&I
Mikados, an 0-8-0, and an ex-Pennsylvania Railroad Consolidation are arrayed around the turntable at Detroit, Toledo & Ironton’s Flat Rock Yard near Detroit on the day before Labor Day, 1955. Philip R. Hastings photo […]
Reading Co. Camelback Ten-Wheeler
As a crossing watchman stands guard, Reading Camelback 4-6-0 No. 608 brings a Newtown, Pa.–Philadelphia local into Fox Chase station in 1948. Leslie R. Ross photo […]
Icing the reefers on the CB&Q
A worker shovels salt into a reefer via a rolling chute at the Chicago, Burlington & Quincy’s icing dock in Denver in 1949. The conveyor chain on the platform at right carries block ice along the platform. Earl Cochran photo […]
Dallas interlocking tower
An interior view at Tower 19 near Dallas (Texas) Union Terminal shows the track diagram (“model board”) of the territory controlled by the tower and some of the levers that controlled the switches and signals. This is an electro-pneumatic interlocking, in which switches are operated by compressed air. Historic American Engineering Record photo […]
Steam locomotive profile: 4-8-4 Northern
With the general speed-up of passenger train schedules in the 1920s, the need arose for a more powerful version of the 4-8-2. Although it had adequate adhesion, the 4-8-2 lacked the raw horsepower to accelerate a heavy train coming out of a sag or after rounding a curve. Lima Locomotive Works had shown the world […]
Century in sections at Chicago
New York Central E8 diesels idle at La Salle Street Station, Chicago, awaiting departure with two sections of the 20th Century Limited in November 1953. Robert W. Carper photo […]
Stock cars and reefers on the Santa Fe
A long string of stock cars is tucked in behind Santa Fe 2-8-2 No. 4085 on train 44, the Perishable Express, near Henrietta, Mo., in 1946. Behind the stock cars are 33 refrigerator cars. Robert R. Malinoski photo […]
Water standpipe
This is a typical standpipe (also called water crane, water column, or water plug) used to fill steam locomotive tenders with water, which is supplied by pipe from a tank. A single tank might supply several standpipes. When not in use, they were swung away from the track. The bucket-like object between the end of […]
